Single-Hand Brake LEFT
Single-Hand Brake LEFT
Single-Hand Brake LEFT

Single-Hand Brake LEFT

One-hand braking system for the Veloped/Walker, where both brakes (R+L) are operated with the left hand by a single brake lever.

Read reviews
SKU: 11-90-016
GTIN: 7350038031983
Stock Status: In Stock
Region: Available
(Item does not ship from the EU to Australia, Canada, or the USA.)
Delivery Status: 3-5 working days
50.42 €
Including Tax: 0 € (0%)
pcs

Get your personalised quote
Tell us what you need, and we’ll send you a personalized quote.
Request a Quote
Receive Your Quote
No obligation • We typically reply within 24 hours
Fast response
No credit card required
Free quote
Simple and secure payment with your Paypal account or with card.
Mastercard is a smarter and secure way to make online payments.
Visa is the largest global card network in the world by transaction value, ubiquitous worldwide.
Accepted in more than 130 countries, and with over 100 million cards in use, American Express (Amex), is a key payment method worldwide.
Klarna Invoice (Pay in 30 days)
Klarna - 3 interest-free instalments
?php echo functions::escape_html(strip_tags(language::translate('pm_mollie:sepa:description', ''))); ?>
You receive the banking details after you have confirmed your order.
The One Hand Brake for the left hand on the Trionic Veloped and Walker rollator, when installed, allows you to control the rollator's brakes with one hand.
  • Brake lever with linear adapter that splits the single brake cable into two.
  • Both brakes (R+L) are operated with one single brake lever.
  • For left side assembly.

User Guides

The documentation for this product includes the manuals and instructions listed below. You can choose to view the documentation online or download it for local use.

Trionic Single-Hand Brake

One-hand brake that brakes the right and left brakes simultaneously.

Assembly: Trionic single-hand brake system (pictures show Right side) 1 Assembly: Trionic single-hand brake system (pictures show Right side)

1. Mount the brake lever on the gripbar (as far to the front as possible).

2. Unscrew the screws (2x 4 pcs) that attach the R & L brake cover.

3. Attach the short brake cable to the brake on the same side as the brake lever.

4. Make sure that the cable-end nipple screw is facing outwards (wheel-direction).

5. Route the longer brake cable through the frame (betw. top & down frame tube).

6. Attach the longer brake cable to the brake positioned on the opposite side of the brake lever.

7. Cut a small hole (2x) through the fabric of the basket at each rear bottom corner (see RED circles in the picture).

8. Fasten the longer brake cable to the basket with the 2 cable-ties.

9. Re-attach the 2 brake covers again, using the 2 cable-ties with a Ø5 mm hole for the 2 upper screws (R + L side).

10. Stick one of the wheel QR-axles (Ø12 mm) through the cable-tie loop, and pull the cable-tie tight around the axle (provides the correct tension in order to avoid that the cable rubs against the tire, but without the brake cable being forced out of direction).

11. The R & L side brake cables can be individually adjusted, by using either the adjuster screws positioned at the brake, or the adjuster screws attached to the linear duplicator.

12. Make sure that the parking brake blocks the wheel completely.

Centering of the brake 2 Centering of the brake

1. Unscrew the brake collar screw 3-4 turns (reached through the brake cover hole).

2. Pull the brake lever and hold it tight.

3. While holding the brake lever tight, fasten the brake collar screw again.

4. Check that the wheel spins freely, without rubbing between brake/brake hub.

If you have any questions, please do not hesitate to contact our product manager Stefan Kindberg; +46-8-522 100 52.

Customer Reviews

Monika Römer
Left single-hand brake and handling
It skews to one side when braking, especially on sloping roads.

I have trouble getting over old town pavements with kerbs.
